Guba 60.2
(GBA)
Ligne: 12'''
Jewels: 15/17/18/21
Lift Angle: 48°
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 27 mm
Height: 4.5 mm
Hands: 1.50 x 0.90 x 0.20 mm
The Guba 60.2 mechanical watch movement is a manual wind movement with a sweep second function. It has the option of additional functions such as month, day, date hand, and moon phase, which can be set using four pushers. The exact differences between the Guba 60.2, 1102, 1104, and 1106 movements are unknown. This movement was commonly used around the year 1955.
The Guba 60.2 features the following functions:
- Manual Winding
- Option: month, day, date hand, moon phase, set by 4 pushers
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4247 | Ordinary/None | Buy staff |
| 834 | Ordinary/None | Buy staff |
| 889 | Incabloc | Buy staff |
| 3228 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.130 x 320 x 10.5 mm | GR4196 | Manual | Buy mainspring |
| 1.50 x 0.130 x 300 x 10.5 mm | Manual | Buy mainspring | |
| 1.50 x 0.120 x 320 x 9.5 mm | GR41761 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
