Gruen N580SS
Ligne: 7'''
Jewels: 21
Power Reserve: 37 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1955
Diameter: 16.3 mm
Height: 5.4 mm
Hands: 1.20 x 0.75 x 0.21 mm
The Gruen N580SS watch movement, produced around 1955, features an optional winding gear made from beryllium bronze. It includes the functions of automatic winding and a sweep second hand.
The Gruen N580SS features the following functions:
- Automatic Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.060 x 220 x 6.0 mm | GR3173X | Auto | Buy mainspring |
| 1.30 x 0.060 x 210 x 6.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
