Gruen 512CD
Ligne: 13'''
Jewels: 17
Lift Angle: 49°
Power Reserve: 48 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1938-1974
Diameter: 30 mm
Height: 6.95 mm
Hands: 1.60 x 1.10 x 0.25 / 0.28 x 0.25 x 0.23 mm
Base: Valjoux 72
The Gruen 512CD watch movement, used from 1938 to 1974, incorporates a Breguet hairspring and features a manual-wind chronograph with 60-second, 30-minute, and 12-hour functions. It also includes a sub-second function and KIF Shock Protection. The movement operates using a pillar wheel.
The Gruen 512CD features the following functions:
- KIF Shock Protection
- Manual-wind chronograph, 60s, 30min, 12h, pillar wheel
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.140 x 12.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| STAFF, GENUINE KIF | 723/1055 | 723/1055 | Buy part |
