Girard Perregaux 80.09
Ligne: 12'''
Jewels: 15/17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 27 mm
Height: 3.8 mm
Hands: 1.50 x 0.80 / 0.20 mm
The Girard Perregaux 80.09 watch movement is a manual wind movement with sub-second function. It is part of a series of movements (26, 262, 263, 265 through 268, 2617, 2620) that are virtually identical, with the only difference being the bridge layouts. The Girard Perregaux 80.09 movement was commonly used around 1955.
The Girard Perregaux 80.09 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.110 x 390 x 11.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
