Girard Perregaux 43.0
Ligne: 19.5'''
Jewels: 7
Power Reserve: 18 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1930
Diameter: 44 mm
Height: 8.1 mm
Hands: 1.35 / 1.35 mm
The Girard Perregaux 43.0 watch movement is an open face calibre featuring a stop function with a pillar wheel. The pendant is mounted on the movement. The calibre signature of early models is poorly recorded, resulting in limited information available. Notable functions of the Girard Perregaux 43.0 include a timer with 60-second increments (with accuracy up to 0.2 seconds) and a 30-minute capability, both operated by a pillar wheel. Optionally, it can also measure time in 30-second intervals (with accuracy up to 0.1 seconds) and 15-minute durations. This movement is stem-wind operated and includes a sweep second hand. It was predominantly utilized around 1930.
The Girard Perregaux 43.0 features the following functions:
- Option: 30s (0.1s), 15min
- Stem wind
- Sweep second
- Timer, 60s (0.2s), 30min, pillar wheel
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 3096 | Ordinary/None | Buy staff |
| 4143 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.90 x 0.150 x 480 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
