General 32BL
(Helvetia)
Ligne: 16.5'''
Jewels: 15
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 37.2 mm
Height: 4.2 mm
Hands: 1.50 x 1.15 / 0.26 mm
The General 32BL is an open face calibre movement that features varying bridge shapes. The specific differences between the Unitas 85 and General 32BL are currently unknown. The movement includes functions such as stem wind and set, as well as sub second display. It was commonly used around the period of 1940.
The General 32BL features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.90 x 0.180 x 450 x 15.0 mm | Manual | Buy mainspring | |
| 1.50 x 0.180 x 420 x 14.0 mm | GR4312 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
