Fleurier 103
Ligne: 12'''
Jewels: 17
Lift Angle: 40°
Power Reserve: 39 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1943-1969
Diameter: 27 mm
Hands: 1.90 x 1.00 x 0.20 / 0.20 x 0.20 x 0.20 mm
Base: Lemania 1281
The Fleurier 103 watch movement is a manual-wind chronograph movement that incorporates a 60-second, 30-minute, and 12-hour timer, with cam switching functionality. It features a sub-second display and is equipped with Incabloc Shock Protection. The Fleurier 103 movement was used during the period from 1943 to 1969.
The Fleurier 103 features the following functions:
- Chronograph Movement
- Incabloc Shock Protection
- Manual-wind chronograph, 60s, 30min, 12h, cam switched
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.120 x 320 x 10.0 mm | GR3311 | Manual | Buy mainspring |
| 1.30 x 0.110 x 300 x 9.0 mm | GR3283 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
