Felsa 4009
Ligne: 12.5'''
Jewels: 23
Lift Angle: 52°
Power Reserve: 42 hrs
Frequency: 28800 vph
Type: Automatic
Period used: 1972-1984
Diameter: 27.9 mm
Height: 4.25 mm
Hands: 1.30 x 0.60 x 0.15 mm
Base: Omega 1010
The Omega 1012 is a mechanical watch movement that was produced from 1972 to 1984 with a total of 126000 units manufactured. In this movement the automatic gear is integrated directly into the movement itself rather than being attached to a manual-wind calibre as is typically done. This design feature allows for a rugged rotor bearing to be accommodated in the center while maintaining a low profile. The Omega 1012 movement offers several functions including an automatic winding system and sweep seconds.
The Felsa 4009 features the following functions:
- Automatic Winding
- Date: quickset
- Hack feature
- Stop Seconds Function
- Sweep Seconds
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 0.95 x 0.120 x 500 x 11.7 mm | GR23781X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
