ETA 2783
Ligne: 12'''
Jewels: 17
Frequency: 21600 vph
Type: Automatic
Period used: ~1975
Diameter: 27 mm
Height: 5.5 mm
Hands: 1.80 x 1.30 x 0.20 mm
The ETA 2783 watch movement is an automatic movement featuring a pin-lever escapement. In some late samples, the hairspring terminal is glued. The stem mechanism operates without a setting-lever spring. The barrel drives the strangely train and hand gear separately. This movement also includes functions such as sweep seconds and automatic winding. The ETA 2783 movement was commonly used during the period around 1975.
The ETA 2783 features the following functions:
- Automatic Winding
- Pin lever
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.105 x 9.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
