ETA 1010
Jewels: 7/11/13/15/17/21
Power Reserve: 33 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1883-1919
Diameter: 45.7 mm
Height: 10.1 mm
Hands: 2.50 x 1.32 / 0.25 mm
The ETA 1010 watch movement, produced between 1883 and 1919, is a hunter calibre timepiece. It features a ratchet on the dial side and a crown mechanism with a rocker bar. The movement incorporates a bimetallic screw balance and a Breguet hairspring, enhancing its precision. A brass escape wheel is employed, along with mostly fine regulation gear, which is mounted on a cock or plate. The movement offers stem wind functionality, with switching possible through either the crown or lever. Additionally, it includes a sub second feature.
The ETA 1010 features the following functions:
- Stem wind, switching by crown or lever
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2716 | Ordinary/None | Buy staff |
| 2526 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 3.00 x 0.220 x 540 x 17.0 mm | GR7208T | T | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
