Elgin 718
Ligne: 6'''
Jewels: 17
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 13.75 mm
Height: 3.2 mm
Hands: 1.00 x 0.50 mm
Base: ETA 2440
The Elgin 718 is powered by the smallest ETA calibre and features an early fixed, later mobile stud carrier. The movement incorporates an indirectly driven minute hand, allowing for a large balance. Additionally, the Elgin 718 is a manual wind movement.
The Elgin 718 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.43 x 0.063 x 201 x 5.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
