Elgin 620
Ligne: 19'''
Jewels: 15
Power Reserve: 35 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1914-
Diameter: 42.9 mm
Height: 5.0 mm
Hands: 1.85 x 1.19 / 0.20 mm
The Elgin 620 watch movement is a period 1914- open face calibre with a bimetallic screw balance and riveted staff. It features a Breguet hairspring, a brass lever, and an escape wheel. The balance with press-fit staff and with riveted staff are completely interchangeable. The movement includes functions such as stem winding and setting, as well as a sub-second hand.
The Elgin 620 features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.00 x 0.200 x 460 x 16.0 mm | GR5902 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
