Return To ShopThe Elgin 444 watch movement is an open face calibre that features a bimetallic screw balance with 4 adjustment screws and a Breguet hairspring. It exhibits varying bridge shapes. This movement has the functions of stem winding and setting, as well as a sub second display. It was commonly used around the year 1949.
The Elgin 444 features the following functions:
Dimensions | GR Reference # | End Type | Buy |
---|---|---|---|
2.10 x 0.200 x 490 x 16.5 mm | Manual | Buy mainspring | |
2.10 x 0.190 x 520 x 16.0 mm | GR6080 | Manual | Buy mainspring |
Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
---|
Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
---|
Part Description | Reference # | Alternate | Buy |
---|---|---|---|
BARREL ARBOR | 195/564 | Buy part | |
PALLET ARBOR | 72S/124P | 714/LAN 39 | Buy part |
SCREW, CLICK | 5425/238 | 5425/RECORD 433 | Buy part |
SCREW, DIAL SIDE | 5750/262 | Buy part | |
SCREW, PLATE | 5110/343 | Buy part | |
SCREW, PLATE | 5110/344 | Buy part | |
SCREW, RATCHET WHEEL | 5415/315 | Buy part | |
STAFF | 100/639 | Buy part | |
STEM | 200/1373F | Buy part |
