Elgin 397
Ligne: 5.75'''
Jewels: 17
Lift Angle: 53°
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 13.4 mm
Hands: 0.98 x 0.45 mm
Base: Universal Geneve 540
The Elgin 397 watch movement is a manual wind movement that is nearly equivalent to the family Universal 540 through 550. It was primarily used during the approximate period of 1955.
The Elgin 397 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.35 x 0.060 x 160 x 5.5 mm | GR3460 | Manual | Buy mainspring |
| 1.35 x 0.060 x 160 x 5.0 mm | GR3460 | Manual | Buy mainspring |
| 1.30 x 0.050 x 180 x 5.0 mm | GR3161 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
