Elgin 293
Ligne: 9.75'''
Jewels: 15
Power Reserve: 32 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1925-
Diameter: 21.7 mm
Height: 3.5 mm
Hands: 1.05 x 0.60 / 0.18 mm
The Elgin 293 watch movement, which was in use from 1925 onwards, features a bimetallic screw balance and a Breguet hairspring. It incorporates a stem mechanism without a setting-lever spring, but further distinctions between the 115 and 116 variants are unknown. The movement is manually wound and includes a sub-second function.
The Elgin 293 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.105 x 265 x 8.5 mm | Manual | Buy mainspring | |
| 1.10 x 0.105 x 260 x 8.5 mm | GR2623 | Manual | Buy mainspring |
| 1.10 x 0.110 x 260 x 8.5 mm | GR2632 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
