Elgin 276
Ligne: 5.75 x 6.75'''
Jewels: 19
Power Reserve: 41 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: ~1960
Size: 13.1 x 15.65 mm
Height: 3.2 mm
Hands: 1.00 x 0.55 mm
The Elgin 276 watch movement features Girocap combined settings for the escapement wheel. The movement includes the functions of manual wind, adjustable stud holder, and Incabloc shock protection. It was commonly used around the 1960s.
The Elgin 276 features the following functions:
- Adjustable Stud Holder
- Incabloc Shock Protection
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.075 x 200 x 6.0 mm | GR3192 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
