Elgin 114
Ligne: 13.25'''
Jewels: 17
Power Reserve: 52 hrs
Frequency: 28800 vph
Type: Manual Wind
Period used: 1985-1998
Diameter: 30.4 mm
Height: 7.0 mm
Hands: 2.00 x 1.20 x 0.25 / 0.18 x 0.18 mm
Base: Valjoux 7760
The Elgin 114 is a manual-wind chronograph movement with a 60-second and 30-minute counter, featuring cam switching. It also includes a sub-second function, quickset date and moon phase, and a hack feature. This movement was commonly used during the period of 1985-1998 for watches that required a chronograph, moon-phase display, and calendar functionality.
The Elgin 114 features the following functions:
- Calendar
- Chronograph Movement
- Date: quickset
- Hack feature
- Manual-wind chronograph, 60s, 30min, cam switched
- Moon phase Complication
- Moon phase: quickset
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.112 x 600 x 12.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
