Election 875
Ligne: 12'''
Jewels: 17
Lift Angle: 50°
Power Reserve: 40 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: 1968-
Diameter: 27 mm
Height: 6.87 mm
Base: Omega 1861
The Election 875 is a manual-wind chronograph movement with various functions, including a 60-second, 30-minute, and 12-hour chronograph, sub seconds, and Incabloc Shock Protection. It went through different periods of plating, starting with pink gold-plated from 1968 to 1992, followed by yellow gold-plated from 1992 to 1996, and finally rhodium-plated from 1996 to the present day. The Election 875 movement has been in use since 1968 and features cam-switched mechanisms.
The Election 875 features the following functions:
- Chronograph Movement
- Incabloc Shock Protection
- Manual-wind chronograph, 60s, 30min, 12h, cam switched
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.130 x 400 x 12.0 mm | GR3342 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
