Dugena 3804
Ligne: 10.5'''
Jewels: 17
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1952
Diameter: 23.7 mm
Height: 4.3 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Dugena 3804 watch movement is a manual-wind movement with a direct sweep second function. It belongs to the first family of movements with a direct sweep second hand. This movement was based on the automatis base and incorporates various shock devices. The Dugena 3804 movement was utilized around 1952.
The Dugena 3804 features the following functions:
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 9.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
