Dugena 3324
Ligne: 11.5'''
Jewels: 27
Power Reserve: 50 hrs
Frequency: 19800 vph
Type: Automatic
Period used: 1996-
Diameter: 26 mm
Height: 5.9 mm
Hands: 1.50 x 0.90 x 0.20 mm
The Dugena 3324 watch movement, introduced in 1996, features a unique design where the train and hand gear are individually driven by the barrel. This automatic movement also includes sub second and Datum-Zeiger functions, with the latter being activated through a pusher located at 4 o'clock.
The Dugena 3324 features the following functions:
- Automatic Winding
- Datum-Zeiger: Schaltung durch Dr?cker bei 4
- Sub second function
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.150 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
