Dugena 3027
Ligne: 10.5'''
Jewels: 15/17/19/21
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 23.7 mm
Height: 4.15 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Dugena 3027 is a manual wind mechanical watch movement that includes a sweep second function. It was most likely produced around 1955. The differences between the Dugena 3027 and other similar movements such as the ETA 1080, 1082, 1084, 1088, 1094, 1096, 1098, 1140, 1142, 1144, 1146, 1148, 1154, 1156, 1174, 1176, 1178, 1180, and 1182 are not known.
The Dugena 3027 features the following functions:
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.110 x 290 x 9.5 mm | Manual | Buy mainspring | |
| 1.50 x 0.105 x 300 x 9.0 mm | GR4134 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
