Dugena 1109
Ligne: 18.5'''
Jewels: 15
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 41.65 mm
Height: 5.3 mm
Hands: 2.00 x 1.15 / 0.27 mm
The Dugena 1109 is an open face calibre watch movement that offers optional Breguet hairspring and varying bridge shapes. It may possibly feature a left-handed ratchet-wheel screw, although further information is not known regarding its differences amidst calibres 231, 235, 239, 243, 249, 255, 259, 265, 271, 277, 447, 449, 471, 477, and 508. These calibre designations are likely catalog designations representing the various bridge shapes. The Dugena 1109 movement, utilized around 1940, implements stem-winding and setting functionalities, along with a sub-second feature.
The Dugena 1109 features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.10 x 0.210 x 490 x 17.0 mm | Manual | Buy mainspring | |
| 2.10 x 0.210 x 480 x 16.0 mm | GR6106 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
