Cyma Tavannes 911
(Cyma, Tavannes)
Ligne: 11.5'''
Jewels: 7/15/17
Power Reserve: 37 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 26 mm
Height: 4.2 mm
Hands: 1.30 x 0.80 / 0.22 mm
The Cyma Tavannes 911 is a mechanical watch movement with a pin-lever escapement and a ratchet on the dial side. It features a crown mechanism with a rocker bar. The 1549 movement is part of a series that includes the 1332, 1473, 1549, 1569, and 1601, although the differences between these specific variations are not known. The movement is manually wound and includes a sub-second function. It was commonly used around the year 1950.
The Cyma Tavannes 911 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.85 x 0.105 x 280 x 9.0 mm | GR5463 | Manual | Buy mainspring |
| 1.80 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| FOURTH WHEEL, W/SECOND | 224/5 | /BET 1549 | Buy part |
