Watch Database
Cyma Tavannes 424K
(Cyma, Tavannes)
Ligne: 13'''
Jewels: 15/17/18/21
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 29.4 mm
Height: 4.5 mm
Hands: 1.50 x 0.90 x 0.20 mm
The Cyma Tavannes 424K is a manual wind watch movement with sweep second function. It is part of a series that includes the ETA 1101, 1103, and 1105, but the specific differences between these movements are unknown. The Cyma Tavannes 424K was commonly used in watches manufactured around 1955.
The Cyma Tavannes 424K features the following functions:
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.130 x 320 x 10.5 mm | GR4196 | Manual | Buy mainspring |
| 1.50 x 0.130 x 300 x 10.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
