Cortebert 540S
Ligne: 11.5'''
Jewels: 17/21
Lift Angle: 52°
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 26 mm
Height: 3.6 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Cortebert 540S is a manual wind watch movement that features a sweep second function along with a date display. The date can be adjusted by changing the time to 20:30-24h.
The Cortebert 540S features the following functions:
- Date: set by changing 20:30-24h
- Manual Winding
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4377 | Ordinary/None | Buy staff |
| 5136 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.110 x 320 x 10.0 mm | Manual | Buy mainspring | |
| 1.30 x 0.110 x 320 x 9.5 mm | GR3284 | Manual | Buy mainspring |
| 1.30 x 0.115 x 320 x 9.5 mm | GR3295 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
Documents
Parts Listing
