Citizen EA2023
The Citizen EA2023 watch movement features an analog display, it does not include a second hand, and it operates on a quartz mechanism.
The Citizen EA2023 features the following functions:
- Analog Display
- Quartz Movement
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BATTERY | SB-AF | EV 321 | Buy part |
| CANNON PINION, HT | 0221902 | 240/1997 | Buy part |
| CASE RING | 82725000 | Buy part | |
| CIRCUIT | 4001832 | X/11632 | Buy part |
| CIRCUIT BLOCK COVER | 4457832 | X/11638 | Buy part |
| COIL BLOCK | 4002832 | X/11633 | Buy part |
| HOUR WHEEL, HT 95 | 0271902 | 250/1685 | Buy part |
| MINUTE WHEEL | 0261902 | 260/1335 | Buy part |
| POSITIVE(+) BATTERY CONNECTION | 4271832 | X/11637 | Buy part |
| ROTOR STATOR | 4239832 | X/11634 | Buy part |
| SCREW,CIR/PL/DATE/COIL,CAP | 0022247 | 5110/947 | Buy part |
| STEM GUIDE PLATE | 0711902 | M/4071 | Buy part |
| STEM, T12 | 0354902 | 401/1112 | Buy part |
| STEP ROTOR | 4146833 | X/11635 | Buy part |
| THIRD WHEEL | 0231705 | 210/1534 | Buy part |
