Alpina 682
(Alpina Straub)
Ligne: 7.75'''
Jewels: 17
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1960
Diameter: 17.5 mm
Hands: 1.20 x 0.60 mm
The Alpina 682 is a manual wind mechanical watch movement with an option for a sub second function. It also includes a date feature. It was primarily used during the approximate period of 1960.
The Alpina 682 features the following functions:
- Date
- Manual Winding
- Option: sub second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.070 x 210 x 6.5 mm | Manual | Buy mainspring | |
| 1.20 x 0.075 x 220 x 6.5 mm | GR2861 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| CANNON PINION, HT 2.49 | 240/1432 | Buy part | |
| CENTER WHEEL | 201/836 | Buy part | |
| GIB/BOLT INCA SHOCK .15 THICK | 400/774 | 180.15/INCA #12 | Buy part |
| JEWEL, INCA BALANCE 105X42X09 | 400/41 | 211.09/INCA #26 | Buy part |
| JEWEL, INCA BALANCE 135X50X09 | 400/11 | 111.09/INCA#8 | Buy part |
| JEWEL, LOWER CAP INCA 90X13 | 400/68 | 222.11/INCA #23 | Buy part |
| JEWEL, UPPER CAP INCA 120X18 | 400/8 | 122.11/INCA #6 | Buy part |
| LOWER SETTING D130 H9 | 400/1483 | 231.20.9 | Buy part |
| SCREW, INCA SHOCK .15X.50 | 400/809 | 150.21/INCA #14 | Buy part |
| SHOCK SPRING, UPPER INCABLOC | 400/4 | 170.03/INCA #1 | Buy part |
| SHOCK UNIT, UPPER (D255 H9) | 100.21.255.9 | Buy part | |
| SPRING,INCA U/L SHOCK 172X114 | 400/66 | 270.02-3/INCA #21 | Buy part |
