Alpina 568
(Alpina Straub)
Ligne: 19.5'''
Jewels: 7
Power Reserve: 14 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1960
Diameter: 44.8 mm
Height: 8.75 mm
Hands: 1.35 / 1.35 mm
Base: Hanhart 36
The Alpina 568 is an open face calibre movement featuring a pin-lever escapement and a stop function controlled by a pillar wheel. Since approximately 1960, it has been equipped with shock protection. Additionally, since around 1970, it has undergone improvements, such as a mobile stud carrier, a new balance-stop, and a revised guide. The watch movement offers various functions including a timer with 60-second accuracy (0.2 seconds) and a 30-minute range, which is controlled by a pillar wheel. An optional version of the movement includes a 30-second timer (0.1 seconds) and a 15-minute range. Furthermore, the Alpina 568 has an addition timer, allows stem winding, features a sweep second hand, and is equipped with a timer function. This movement was in use around 1960, with specific production years not further elaborated.
The Alpina 568 features the following functions:
- Addition timer
- Option: 30s (0.1s), 15min
- Stem wind
- Sweep second
- Timer function: 60s (0.2s), 30min, pillar wheel
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.95 x 0.200 x 360 x 15.5 mm | Manual | Buy mainspring | |
| 1.90 x 0.190 x 500 x 15.5 mm | GR5644 | Manual | Buy mainspring |
| 1.90 x 0.200 x 440 x 14.0 mm | GR5658 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
