Alpina 227
(Alpina Straub)
Ligne: 10.5'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1962
Diameter: 23.7 mm
Height: 4.45 mm
Hands: 1.30 x 0.70 mm
Base: Angelus 123
The Alpina 227 watch movement is likely manufactured by Angelus, based on the information provided by Flume catalogs. It is a manual wind movement with sub-second and sweep seconds functions. The Alpina 227 movement was in use around 1962.
The Alpina 227 features the following functions:
- Manual Winding
- Sub Second
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1506 | Ordinary/None | Buy staff |
| 1581 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.110 x 260 x 8.0 mm | GR4147 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| CANNON PINION, SS HT 2.05 | 245/847 | 6061 | Buy part |
| MAINSPRING 1.50-.11-260 8 | MS-610H | GR 4147 | Buy part |
| PALLET ARBOR | 72S/99P | 714/AS 1290 | Buy part |
| ROLLER 210X85X37 | 82S/62R | Buy part | |
| STAFF | 100/18 | Buy part | |
| STEM | 200/24F | Buy part | |
| WINDING PINION | 410/1055 | Buy part |
