A. Schild 746
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1975
Diameter: 26 mm
Height: 4.7 mm
Hands: 1.40 x 0.90 x 0.18 mm
The A. Schild 746 watch movement, manufactured approximately in 1975, is a manual wind movement with a sweep second function. It also incorporates a calendar complication that can be set by adjusting the 22-24 hour range. The movement features an indirectly driven minute hand, enabling a larger balance and a low profile design.
The A. Schild 746 features the following functions:
- Calendar
- Date: set by changing 22-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.120 x 10.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
