A. Schild 738
(AS, A Schild)
Ligne: 13'''
Jewels: 15/17
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 29.33 mm
Hands: 1.58 x 0.98 x 0.20 mm
Base: Universal Geneve 267
The A. Schild 738 is a manual wind mechanical watch movement that was widely used around 1945. It features a Breguet hairspring and encompasses several functions, including a sweep second hand and a date display.
The A. Schild 738 features the following functions:
- Date
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2485 | Ordinary/None | Buy staff |
| 3715 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.120 x 320 x 9.5 mm | GR2973 | Manual | Buy mainspring |
| 1.20 x 0.130 x 300 x 9.5 mm | GR2988 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
