A. Schild 5200
(AS, A Schild)
Ligne: 10.5'''
Jewels: 15
Power Reserve: 44 hrs
Frequency: 18000 vph
Type: Manual Wind
Height: 4.0 mm
Hands: 1.40 x 0.70 / 0.21 mm
The A. Schild 5200 watch movement is a manual wind movement with sub-second functionality. It is available in an optional 11.5''' size and has a variety of bridge layouts. Some of these movements may be labeled as FHF 150, and they may also have individual designations in old data sheets. The specific differences between the 150, 151, 156, 158, 159, 162-164, 166, 174, 178, 187, 201, 203, and 208 variations are not known. Additionally, variations with both sweep seconds and non-sweep seconds are available.
The A. Schild 5200 features the following functions:
- Manual Winding
- Sub Second
- Sweep seconds and non-sweep seconds variations
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1062 | Ordinary/None | Buy staff |
| 1038 | Ordinary/None | Buy staff |
| 2674 | Incabloc | Buy staff |
| 639 | Shock Resist | Buy staff |
| 3214 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.100 x 320 x 9.0 mm | GR5254 | Manual | Buy mainspring |
| 1.80 x 0.100 x 300 x 9.0 mm | GR5253 | Manual | Buy mainspring |
| 1.80 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
