A. Schild 1876
(AS, A Schild)
Ligne: 7.75'''
Jewels: 21
Power Reserve: 30 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1975
Diameter: 17.5 mm
Height: 4.9 mm
Hands: 1.20 x 0.70 x 0.20 mm
Base: Forster 422
The A. Schild 1876 is an automatic watch movement with a sweep second hand and a date function that is set by changing the 23-24 hour marker. This movement features an indirectly driven minute hand, allowing for a large balance and a low-profile design. The barrel in this movement is equipped with jewel bearings. The A. Schild 1876 movement was commonly used around the year 1975.
The A. Schild 1876 features the following functions:
- Automatic Winding
- Date: set by changing 23-24h
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.075 x 6.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
