A. Schild 1827
(AS, A Schild)
Ligne: 11.5'''
Jewels: 21
Power Reserve: 42 hrs
Frequency: 28800 vph
Type: Automatic
Period used: 1999-
Diameter: 26.2 mm
Height: 4.35 mm
Hands: 1.50 x 0.90 / 0.20 mm
The A. Schild 1827 is a watch movement that was introduced in 1999. It shares many technical details with the ETA 2892 movement. This automatic movement features a sub second function, along with a quickset date feature and a hack feature. The A. Schild 1827 has been used in watches since 1999.
The A. Schild 1827 features the following functions:
- Automatic Winding
- Date: quickset
- Hack feature
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.05 x 0.115 x 475 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| ADDITIONAL INTERMEDIATE WHEEL | M/5049 | 204/ETA 2895-2 | Buy part |
| ADDITIONAL SECOND WHEEL | M/5043 | 222/ETA 2895-2 | Buy part |
| BALL BEARING | A/9590 | 1497/ETA 2892-2 | Buy part |
| BALL BEARING | A/9577 | 01497.2890.2 | Buy part |
| BARREL BRIDGE | M/5103 | 00105.2892-2.03005 | Buy part |
| BARREL BRIDGE, NICKEL | M/5018 | 00105.2892-2.03005 | Buy part |
| CLICK PLATE | M/3037 | 00511.2890 | Buy part |
| ESCAPE WHEEL | 705/1440 | 705/ETA 2895-1 | Buy part |
| FOURTH WHEEL, SS | 227/1296 | Buy part | |
| HOUR WHEEL, SS HT 2.79 | 255/1425 | 00255.2892A2.104 | Buy part |
| INERMEDIATE SECOND WHEEL | 215/ETA 2895-2 | Buy part | |
| INTERMEDIATE (CENTER) WHEEL | 203/175 | 203.2890 | Buy part |
| MAINSPRING 1.05-.115-480 10,5 | A/9207 | 00771.2894-2.2 | Buy part |
| RATCHET WHEEL DRIVING WHEEL | A/8499 | 01482.2890 | Buy part |
| SCREW, FRAMEWORK | A/8508 | 51134/ETA 2890 | Buy part |
| SET BRIDGE/CLUTCH LEVER SPRING | 445/1282 | 00445.2890.2 | Buy part |
| SET LEVER, W/AXLE | 443/1480 | 00443.2892-2.3200075 | Buy part |
| STUD SUPPORT (375/ETA 2897) | M/5076 | 4020000.28952.297865 | Buy part |
| TECH SHEET | TS/ETA 2895-2 | Buy part |
