A. Schild 1700
(AS, A Schild)
Ligne: 8.25'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 39 hrs
Frequency: 18000 vph
Type: Automatic
Period used: 1950-1957
Diameter: 18.55 mm
Height: 5.3 mm
Hands: 1.20 x 0.70 x 0.21 mm
The A. Schild 1700 watch movement, produced from 1950 to 1957, manufactured a total of 157,275 units. It is equivalent to the Eterna 1195 to 1199 movements and features automatic winding and a sweep second function.
The A. Schild 1700 features the following functions:
- Automatic Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.075 x 220 x 6.5 mm | GR3193X | Auto | Buy mainspring |
| 1.30 x 0.070 x 210 x 6.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
