A. Schild 1699
(AS, A Schild)
Ligne: 8.75 x 12'''
Jewels: 15/21
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Size: 19.9 x 27.15 mm
Height: 5.15 mm
Hands: 2.05 x 1.40 x 0.80 / 0.18 mm
The A. Schild 1699 watch movement features a ratchet on the dial side and a crown mechanism with a rocker bar. It exhibits distinct bridge and plate shapes, distinguishing it from other watch movements. The movement offers manual winding, a sub-second function, and a date hand that can be set by +/-24 hours.
The A. Schild 1699 features the following functions:
- Date hand: set by +/-24h
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 3581 | Ordinary/None | Buy staff |
| 3582 | Ordinary/None | Buy staff |
| 3581 | Kif | Buy staff |
| 3582 | Kif | Buy staff |
| 3919 | Monorex | Buy staff |
| 3581 | Rufarex | Buy staff |
| 3582 | Rufarex | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.110 x 260 x 8.0 mm | GR4904 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
