A. Schild 1659
(AS, A Schild)
Ligne: 12.75'''
Jewels: 17
Lift Angle: 50°
Power Reserve: 42 hrs
Frequency: 19800 vph
Type: Automatic
Period used: ~1946
Diameter: 28.5 mm
Height: 4.8 mm
Hands: 1.40 x 0.65 / 0.15 mm
The A. Schild 1659 watch movement is a variant of the 340 movement, created in 1948. It features an automatic (bumper) design and incorporates a sub second function. The movement is Automatic and includes the Incabloc Shock Protection feature. It was commonly used during the period around 1946.
The A. Schild 1659 features the following functions:
- Automatic (bumper)
- Incabloc Shock Protection
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1878 | Ordinary/None | Buy staff |
| 1385 | Ordinary/None | Buy staff |
| 3798 | Kif | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.095 x 300 x 9.0 mm | GR2605X | Auto | Buy mainspring |
| 1.10 x 0.100 x 250 x 8.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
