A. Schild 1607
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17/21
Lift Angle: 52°
Power Reserve: 44 hrs
Frequency: 18000 vph
Type: Automatic
Period used: ~1965
Diameter: 26 mm
Height: 5.2 mm
Hands: 1.50 x 0.90 x 0.21 mm
The A. Schild 1607 watch movement features an indirectly driven minute hand, enabling a significant balance size and low profile. Additionally, this movement incorporates automatic winding, sweep seconds, and a calendar function that can be set by adjusting the 20-24 hour timeframe. It is equipped with Incabloc Shock Protection, ensuring durability and reliability. The A. Schild 1607 movement was primarily utilized during the period around 1965.
The A. Schild 1607 features the following functions:
- Automatic Winding
- Calendar
- Date: set by changing 20-24h
- Incabloc Shock Protection
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.100 x 380 x 10.0 mm | GR3957X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More | |||
| See More |
Documents
Parts Listing
