A. Schild 1607
(AS, A Schild)
Ligne: 12.75'''
Jewels: 17/21/25
Frequency: 18000 vph
Type: Automatic
Period used: ~1965
Diameter: 28.95 mm
Height: 7.8 mm
Hands: 1.45 x 0.80 x 0.21 mm
The A. Schild 1607 watch movement is characterized by a jewel-bearing rotor and a detached manual wind mechanism. It encompasses several functions including automatic winding and a sweep seconds hand. Additionally, it features a date function that can be set within a range of +/- 24 hours. The movement was commonly used during the approximate period of 1965.
The A. Schild 1607 features the following functions:
- Automatic Winding
- Date: set by +/-24h
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.110 x 9.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| SCREW, SET LEVER | 5443/1190 | Buy part | |
| STAFF, SHOCK | 100/1592 | Buy part | |
| STEM | 200/1411F | Buy part |
