A. Schild 1583
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17/21/25
Lift Angle: 52°
Power Reserve: 42 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1965
Diameter: 26 mm
Height: 4.6 mm
Hands: 1.50 x 0.90 x 0.21 mm
The A. Schild 1583 watch movement features an indirectly driven minute hand, which enables the incorporation of a large balance and a low-profile design. It is an automatic movement with a sweep seconds hand. The movement includes a calendar function, where the date can be adjusted by changing the time to 20:20-24h. It also utilizes shock protection for enhanced durability. The A. Schild 1583 movement was predominantly used around the year 1965.
The A. Schild 1583 features the following functions:
- Automatic Winding
- Calendar
- Date: set by changing 20:20-24h
- Shock Protection
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.120 x 320 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
Documents
Parts Listing
