A. Schild 1476N
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17
Lift Angle: 52°
Frequency: 21600 vph
Type: Automatic
Period used: ~1975
Diameter: 26 mm
Height: 6.05 mm
Hands: 1.40 x 0.90 x 0.21 mm
The A. Schild 1476N watch movement is characterized by a unique design where the train and hand gears are driven separately by the barrel. This design allows for a low profile and creates space for a large balance. However, it necessitates precise and shake-free gears due to the involvement of multiple wheels in the coupling between the second and minute hands. The movement features several functions, including automatic winding, sweep seconds, quickset day display, quickset date display, as well as a day and date display. It was primarily used during the period around 1975.
The A. Schild 1476N features the following functions:
- Automatic Winding
- Date: quickset
- Day and Date Display
- Day: quickset
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.120 x 325 x 10.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
