A. Schild 1442N
(AS, A Schild)
Ligne: 19.5'''
Jewels: 15
Frequency: 3600000 vph
Type: Manual Wind
Period used: 1962-
Diameter: 48.8 mm
Height: 7.1 mm
Hands: 1.20 x 1.20 x 0.26 mm
The A. Schild 1442N is an open face calibre watch movement with a winding gear that features a rocker on the back side. It incorporates a timer with various functionalities, including 0.1s (0.01s), 6s, 6min, and a pillar wheel. The movement is designed for stem winding and includes sub dials for measuring 1/100 seconds, seconds, and minutes. Additionally, it includes a stop over wheel on the escape-wheel arbor to measure 1/100 seconds. Early samples of the movement also featured an additional balance brake. The A. Schild 1442N movement has been used since 1962.
The A. Schild 1442N features the following functions:
- In early samples additional balance brake
- Stem wind
- Stop over wheel on escape-wheel arbor (1/100 seconds)
- Sub dials for 1/100 seconds, seconds, minutes
- Timer, 0.1s (0.01s), 6s, 6min, pillar wheel
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.40 x 0.200 x 15.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
