A. Schild 1423
(AS, A Schild)
Ligne: 7.75'''
Jewels: 17
Lift Angle: 50°
Power Reserve: 39 hrs
Frequency: 198000 vph
Type: Automatic
Period used: ~1965
Diameter: 17.5 mm
Height: 4.5 mm
Hands: 1.10 x 0.60 mm
Base: Buren 06
The A. Schild 1423 watch movement is a detached manual wind and selfwinding gear mechanism featuring a pinion floating between two large jewels to enable direction switching. Its ratchet is located on the dial side, and it is equipped with a crown mechanism with a rocker bar. This movement incorporates several functions including automatic winding, date display, calendar, and it was commonly used during the period around 1965.
The A. Schild 1423 features the following functions:
- Automatic Winding
- Calendar
- Date
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.00 x 0.080 x 7.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
