A. Schild 1396N

(AS, A Schild)

Ligne: 11.5'''

Jewels: 17/21/25

Lift Angle: 50°

Power Reserve: 40 hrs

Frequency: 28800 vph

Type: Automatic

Period used: 1979-1982

Diameter: 26 mm

Height: 5.1 mm

Hands: 1.50 x 0.90 x 0.25 mm

Buy this movement

The A. Schild 1396N watch movement, produced from 1979 to 1982, encompasses several functions including automatic winding, a sweep second hand, a day display with quickset and multilingual options, a date display with quickset function, and a hack feature for precise time setting. It was manufactured in approximately 1,299,477 units during its period of use.

The A. Schild 1396N features the following functions:

Automatic Winding
Date: quickset
Day and Date Display
day: quickset, 2 languages
Hack feature
Stop Seconds Function
Sweep second

Mainspring Listing

Dimensions	GR Reference #	End Type	Buy
1.25 x 0.125 x 420 x 10.5 mm	GR3149X	Auto	Buy mainspring
1.23 x 0.134 x 400 x 10.5 mm		Auto	Buy mainspring

Parts Listing

Part Description	Reference #	Alternate	Buy
AUTOMATIC BRIDGE, LOWER	A/6366	7613226025998	Buy part
BALANCE COMPLETE, SHOCK 3-ARM	721/2020	00721.2801-2.11	Buy part
BALANCE STOP (HACK) LEVER	A/7071	9433.2724	Buy part
BALL BEARING UNIT W/WHEEL	A/6337	01497.2620R	Buy part
BARREL	182/1281	00182.2820.04	Buy part
BARREL ARBOR	195/1318	7613226023475	Buy part
CANNON PINION, HT 1.95	240/1889	242/1/ETA 2804-	Buy part
CANNON PINION, SS HT 1.95	245/862	242/ETA 2500	Buy part
CANNON PINION, SS HT 2.70	245/1019	00242.2500.04	Buy part
CANNON PINION, SS HT 2.95	245/1020	242/ETA 2758	Buy part
CANNON PINION, SS HT 3.20	245/1021	242/ETA 2503	Buy part
CENTER PIPE	M/2704	00161.2800	Buy part
CENTER WHEEL, OFFSET	203/150	7613226041271	Buy part
CLICK	425/954	00425.2776	Buy part
CLICKSPRING	430/1014	00430.2776	Buy part
CLUTCH LEVER	435/1032	00435.2801-2	Buy part
CLUTCH WHEEL	407/1154	407/ETA 2816-1	Buy part
CROWN WHEEL	420/1189	00420.2620	Buy part
DATE DIAL, CURVED	A/8326	02557.2836.B	Buy part
DATE DIAL, FLAT @3	A/8325	02557.2836.P	Buy part
DATE DRIVE WHEEL W/HOLE	A/8751	2555/1-ETA 2836	Buy part
DATE DRIVE WHEEL W/PIVOT	A/8223	2555/ETA 2769-1	Buy part
DATE JUMPER GUARD	A/8324	7613226055667	Buy part
DAY CORRECTOR	A/8228	02567.2836	Buy part
DAY DIAL GIB	A/8234	2780.2836	Buy part
DAY DIAL, ENGLISH @3	A/8327	J2561.2836.000101	Buy part
DAY DIAL, ENGLISH/SPANISH @3	A/8328	J2561.2836.000140	Buy part
DAY/DATE JUMPER, DOUBLE SPRING	A/8235	02784.2836	Buy part
DIAL FOOT CLAMP	M/2619	00144.2850	Buy part
DIAL REST	A/7650	7613226055933	Buy part
DOUBLE CORRECTOR OPER. LEVER	A/8427	02570.2852	Buy part
DOUBLE CORRECTOR WHEEL	A/8229	02569.2836	Buy part
DRIVING WHEEL FOR RATCHET WHL	A/7633	1482.2820	Buy part
ESCAPE WHEEL, S/S	705/1318	00705.2801.112	Buy part
FOURTH WHEEL HT 4.15	220/889	220/889	Buy part
FOURTH WHEEL, SS HT 5.30	227/750	00227.2801.03	Buy part
FOURTH WHEEL, SS HT 5.55	227/734	00227.2801.04	Buy part
FOURTH WHEEL, SS HT 5.80	227/751	00227.2801.05	Buy part
FOURTH WHEEL, SS HT 6.05	227/752	00227.2801.06	Buy part
FRAMEWORK (UPPER AUTO BRIDGE)	A/7649	7613226056367	Buy part
HOUR WHEEL, SS HT 1.01	255/741	250/2600.101	Buy part
HOUR WHEEL, SS HT 1.51	255/746	255/2600.103	Buy part
HOUR WHEEL, SS HT 1.76	255/961	00255.2836.04	Buy part
HOUR WHEEL, SS HT 1.76	255/743	255/2600.104	Buy part
HOUR WHEEL, SS HT 2.00	255/744	00255.2836.05	Buy part
HOUR WHEEL, SS HT 2.26	255/745	255/ETA 2600 H6	Buy part
HOUR WHEEL, SS HT 2.75	255/954	255/954	Buy part
INTERMEDIATE DATE WHEEL	A/8222	02543.2836	Buy part
MAINSPRING, AUTO 1.25X.125X420	A/7652	00771.2821.2	Buy part
MINUTE COCK	462/240	7613226034495	Buy part
MINUTE WHEEL	260/1027	00260.2600	Buy part
OSCILLATING WEIGHT W/BALL BEAR	A/7631	1143/2824-2.00	Buy part
PALLET ARBOR	72S/160	00714.31.09.90	Buy part
PALLET FORK & ARBOR	710/1300	00710.2824-2.439725	Buy part
RATCHET WHEEL	415/1313	415.2820	Buy part
REDUCTION GEAR	A/7632	1481.2820	Buy part
REGULATOR ADJ, (FOR 301/1382)	M/2719	00358.2892A2.297926	Buy part
REGULATOR, 2 PIECE FOR 358	301/1499	301/1499	Buy part
REGULATOR, W/STUD HOLDER	301/1498	307/2/ETA 2801-	Buy part
REVERSING WHEEL W/O PINION	A/7635	01530.2820.0	Buy part
REVERSING WHEEL W/PIN, 17/23J	A/7634	1488.2820.0	Buy part
ROLLER	82S/372R	00730.2801-2.68-75	Buy part
SCREW, BALL BEARING (AXLE)	A/6339	2204001.286907	Buy part
SCREW, BAR/BAL/PAL BRIDGE	5110/753	1005801.286897	Buy part
SCREW, CASE	5101/293	5101/293	Buy part
SCREW, CASE SPECIAL	5102/58	5102/58	Buy part
SCREW, CROWN WHEEL	5420/763	3102301.286904	Buy part
SCREW, DAY CORRECTOR	A/8236	5320101.286912	Buy part
SCREW, FRAMEWORK	A/6373	51134/ETA 2770	Buy part
SCREW, LOWER AUTO BRIDGE	5110/807	12.051.01.286906	Buy part
SCREW, MINUTE COCK	5445/479	5462/ETA 2820	Buy part
SCREW, RATCHET WHEEL	5415/638	3102001.286903	Buy part
SCREW, SET BRDG/DATE JUMP GUAR	5445/523	1311101.286909101	Buy part
SET BRIDGE/CLUTCH LEVER SPRING	445/1328	00445.2804-2.2	Buy part
SET LEVER WITH AXLE	443/1528	00443.2801-2.1	Buy part
SET WHEEL	450/1121	00450.2801-2	Buy part
STAFF	723/1244	00728.2722.BP	Buy part
STAFF, SHOCK BALANCE .90	100/2701	00728.2722.BP	Buy part
STEM, MALE OA 8.15	360/546	404/ETA 952.101	Buy part
STEM, TAP 10	401/843	405/952.101	Buy part
THIRD WHEEL	210/1366	7613226051010	Buy part
UNLOCKING YOKE	A/8230	02632.2836	Buy part
UNLOCKING YOKE MAINT PLATE	A/8232	02644.2836	Buy part
UNLOCKING YOKE SPRING	A/8231	02633.2836	Buy part
WINDING PINION	410/1284	410/1284	Buy part
