Return To ShopWatch Database
A. Schild 1376
(AS, A Schild)
Ligne: 16.5'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 37.2 mm
Height: 4.9 mm
Hands: 2.00 x 1.15 / 0.27 mm
The A. Schild 1376 is an open face calibre watch movement with varying bridge shapes. It likely incorporates a left-handed ratchet-wheel screw. The specific differences between the 283, 291, 297, 309, 329, 333, 337, and 499 are not known. The A. Schild 1376 movement supports the functions of stem winding and setting, as well as featuring a sub-second display. It was commonly used around the period of 1940.
The A. Schild 1376 features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.90 x 0.170 x 460 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
