A. Schild 1354
(AS, A Schild)
Ligne: 11.25'''
Jewels: 17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1955-1967
Diameter: 25.8 mm
Height: 4.0 mm
Hands: 1.41 x 0.79 x 0.18 mm
The A. Schild 1354 manual wind watch movement is characterized by a period of use from 1955 to 1967. It features a mounting flange and includes a Kif-Duofix combined setting for the escape wheel. Additionally, it is likely to have a left-handed ratchet-wheel screw, similar to the 84/S3 movement. The movement also includes a sweep seconds function.
The A. Schild 1354 features the following functions:
- Manual Winding
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.120 x 320 x 10.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BALANCE COMPLETE | 721/1597 | Buy part | |
| ROLLER, 185X75X36 | 82S/50R | Buy part | |
| SCREW, SET LEVER | 5443/1125 | 5443/JUN 684 | Buy part |
| SET BRIDGE | 445/344 | Buy part | |
| SHOCK | 100/2026 | Buy part | |
| STEM | 200/1221F | Buy part |
