A. Schild 1314
(AS, A Schild)
Ligne: 8.75 x 12'''
Jewels: 15
Power Reserve: 50 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1930
Size: 19.95 x 26.85 mm
Height: 3.4 mm
Hands: 1.40 x 0.65 / 0.20 mm
Base: Fontainemelon 29
The A. Schild 1314 watch movement is a manual wind mechanical movement with a sub-second function and jump hour feature. It was commonly used in watches produced around the 1930s. Technical differences between the A. Schild 1314 movement and other movements such as the 29, 57, 58, 68, 77, 94, 98, 106, 111, 127, 149, 225, and 8244 are not currently known.
The A. Schild 1314 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.35 x 0.110 x 400 x 11.0 mm | Manual | Buy mainspring | |
| 1.10 x 0.110 x 400 x 11.0 mm | GR2639 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BALANCE COMPLETE | 721/283 | 721/283 | Buy part |
| SPRING, FLAT HOUR JUMPER | 77/FF 53 FLAT | Buy part | |
| SPRING, WIRE HOUR JUMPER | 77/FF 53 WIRE | Buy part | |
| STAFF | 100/179 | Buy part |
