A. Schild 1292
(AS, A Schild)
Ligne: 10.5'''
Jewels: 15
Power Reserve: 37 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 23.7 mm
Height: 4.05 mm
Hands: 1.30 x 0.65 / 0.21 mm
The A. Schild 1292 is a manual wind watch movement with a sub second function. It was used during the period of approximately 1940. Details regarding the specific differences between the A. Schild 1292 and other similar movements, such as the 148, 150-152, 154, 156-158, and 165, are not known. Additionally, there are variations in bridge shapes for the A. Schild 1292 movement.
The A. Schild 1292 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.50 x 0.105 x 280 x 9.0 mm | GR41332 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
