A. Schild 1249
(AS, A Schild)
Ligne: 10.5'''
Jewels: 15/17
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 23.7 mm
Height: 4.2 mm
Hands: 1.40 x 0.70 mm
The A. Schild 1249 watch movement is a mechanical movement with manual winding and sub-second functions. It was used in watches produced around 1940. There are various bridge shapes for this movement. Further details regarding the differences between the A. Schild 1249 movement and other similar movements, such as 1, 10.5''', 2, 10.5''', 30, 31, 50, 65 old, 66 old, 70 old, 71 old, 73 old, 76 old, 78, 90, 91, 107, 108, 110, and 112, are not known.
The A. Schild 1249 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.30 x 0.110 x 400 x 11.0 mm | GR3288 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
