A. Schild 1220
(AS, A Schild)
Ligne: 19'''
Jewels: 15
Power Reserve: 35 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1929-
Diameter: 43.25 mm
Height: 4.5 mm
Hands: 1.60 x 0.85 / 0.27 mm
The A. Schild 1220 is a hunter calibre watch movement introduced in 1929. It features a bimetallic screw balance with 4 adjustment screws and a Breguet hairspring. The J43 has a separate escape-wheel cock and was produced specifically for Alpina watches. It is uncertain whether these calibres were also used in Junghans timepieces. The J43 movement offers stem winding and setting, a sub-second display, and a hack feature. Its period of use spans from 1929 onwards.
The A. Schild 1220 features the following functions:
- Hack feature
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.210 x 440 x 16.0 mm | GR4362 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
